Product Description
Sample bag
3 Side Sealing, Center Sealing, Center Sealing +gusset, Zipper Sealing, third film inserting Stand up pouch
unwinding device:folding device:
Vertical sealing device and gusset device
bottom sealing device
contral deivce:
Technical Parameter:
model | CW-600C+CS | |||
width of unwinding | 1200mm | |||
length of bag making | 70-380mm*N(N<=6) | |||
width of bag making | ||||
3 sides seal bag | 70-580mm | |||
4 side seal bag | 100-200mm | |||
central seal | 100-450mm | |||
central seal gusset | 100-330mm | |||
stand up zipper bag | 70-260mm | |||
bag making speed | 100-170pcs/min | |||
line speed | 35m/min | |||
total power | 52kw | |||
machine dimension | 12500*2400*2000mm | |||
machine weight | 4500kg |
