Product Description
Sample bag
This machines can production 3 Side Sealing bag,4 Side Sealing bag,3 Side Sealing bag with zipper, Single film insert doypack pouch with zipper.
unwinding device:
folding device:
Vertical sealing device and gusset device
bottom sealing device
Technical Parameter:
model | CW-600ZF+SZ | |||
width of unwinding | 1200mm | |||
pouch making height | 100-350mm | |||
width of bag making | ||||
3 sides seal bag | 100-350mm | |||
4 sides seal bag | 100-350mm | |||
| central seal bag | 100-550mm | |||
stnad up zipper bag | 70-260mm | |||
bag making speed | 100-170pcs/min | |||
line speed | 35m/min | |||
total power | 34kw | |||
machine dimension | 1000*2000*1700mm | |||
machine weight | 4500kg | |||
